601 G12R Solar Panel

Get a Price/Quote

MOQ : 1 Unit

601 G12R Solar Panel Specification

Maintenance Type
Minimal (Periodic Cleaning)

Features
High Power Output, PID Resistant, Half-cell Technology, High Performance in Low Light

Input Voltage
Not Applicable (Solar Panel is a generator)

Efficiency
21.3% (Module Efficiency)

Product Type
Solar Panel

Material
Monocrystalline Silicon

Number of Cells
132 (G12R Format)

Power
610W

Operating Temperature
-40C to +85C

Max Voltage
49.3V (Vmp)

Max System Voltage
1500V DC

Output Voltage
48V (Nominal)

Cable Length
Standard 1 m with MC4 connectors

Switch Mode
No

Size
Standard Large Panel

Dimension (L*W*H)
2172 mm x 1303 mm x 35 mm (Approx.)

Color
Black with Silver/White Frame

Weight
31.5 kg

Application
Commercial/Industrial/Utility

Type Of Technology
Monocrystalline PERC (Passivated Emitter and Rear Contact)

Installation Type
Rooftop/Ground Mount

Short Circuit Current (Isc)
15.2A

Junction Box Rating
IP68

Fire Rating
Class C

Frame Material
Anodized Aluminium Alloy

Panel Type
Bifacial Option Available

Connector Type
MC4 or compatible

Product Code
601 G12R

Open Circuit Voltage (Voc)
58.4V

Glass Type
3.2mm Tempered AR Coated

601 G12R Solar Panel Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

601 G12R Solar Panel About

Experience exceptional efficiency and optimum performance with the 601 G12R Solar Panel, now available at the lowest price through advance purchase-order today! Featuring bifacial capability and advanced Monocrystalline PERC technology, this panel delivers inestimable power output up to 610W with a high module efficiency of 21.3%. The rugged 3.2mm tempered AR-coated glass and anodized aluminium alloy frame ensure durability, while the IP68-rated junction box safeguards reliability. Ideal for commercial, industrial, and utility applications, it's resistant to PID and designed for minimal maintenance. Secure India's most dependable solar innovation for your sustainable needs.

601 G12R Solar Panel: Broad Application for Maximum Advantage

The 601 G12R Solar Panel excels across diverse surfaces, from massive industrial rooftops to expansive ground-mounted utility installations. Its robust build and high-efficiency Monocrystalline PERC cells make it perfect for commercial, industrial, and utility-scale projects. Engineered to withstand challenging environments, it maximizes energy harvest even in low light conditions. Users benefit from advanced bifacial technology, which captures sunlight from both sides for inestimable energy gain, while minimal maintenance ensures seamless, long-term operation and exceptional lifecycle value.

Reliable Supply, Safe Packaging, and Swift Delivery Commitment

Order completion and supply ability are streamlined by extensive inventory and robust logistics, assuring prompt delivery. Panels are securely packaged to protect against transit impacts and adverse conditions, maintaining their pristine quality. Freight arrangements ensure the panels are carefully dispatched to your site anywhere in India. Sample availability is provided for evaluation prior to bulk orders, supporting smooth procurement for suppliers, traders, and service providers seeking consistent solar excellence.

FAQ's of 601 G12R Solar Panel:

Q: How does the 601 G12R Solar Panel perform in low light or variable weather conditions?

A: The 601 G12R Solar Panel incorporates high-performance half-cell technology and bifacial design, ensuring superior power output even in low light or cloudy weather. This results in exceptional reliability and optimum energy generation throughout the day.

Q: What are the advantages of choosing the bifacial panel option for the 601 G12R?

A: The bifacial option enables the panel to harness sunlight from both sides, significantly increasing overall energy yield. This translates to greater efficiency and maximized returns for commercial, industrial, and utility projects.

Q: When can I expect my order to be dispatched after placing an advance purchase request?

A: Once your advance purchase order is confirmed, panels are typically dispatched within the agreed lead time, depending on existing inventory and freight schedules. Your order completion is our priority, ensuring timely delivery.

Q: Where can the 601 G12R Solar Panel be installed for optimum benefit?

A: This panel can be installed on rooftops or ground-mounted structures. Its robust construction and advanced features make it suitable for diverse commercial, industrial, and utility-scale solar installations across India.

Q: What is the maintenance process for the 601 G12R Solar Panel?

A: The panel is designed for minimal upkeep, requiring only periodic cleaning to maintain its efficiency and performance. No complex maintenance procedures are necessary due to its advanced technology and durable construction.

Q: How can suppliers or traders request a sample of the 601 G12R Solar Panel?

A: Samples are available upon request. Interested suppliers, traders, or service providers can contact us to schedule sample dispatch prior to confirming bulk orders, ensuring product suitability.
